Standard Tube Dimensions

Standard Tube Dimensions

EPTAHUB provides instant pricing and lead time estimates for custom tube fabrication solutions, encompassing laser tube cutting and tube bending. This article details the standard round, square, and rectangular tube stock selections available through EPTAHUB.

  • Circular (General)
  • Circular Stainless Alloy
  • Circular Aluminum Tubing
  • Circular Steel Tubing
  • Square or Rectangular Profiles
  • Square/Rectangular Stainless Alloy
  • Square/Rectangular Aluminum Profiles
  • Square/Rectangular Steel Profiles
Industrial laser tube cutting machine fabricating a square metal tube to standard dimensions.

What Tube Sizes Does EPTAHUB Offer for Bending and Cutting?

EPTAHUB delivers tube bending and laser tube cutting services via its Instant Quoting Engine. Simply upload your tube design to receive an immediate quote, along with pricing details and manufacturability feedback.

Tube Bending

EPTAHUB's tube bending services are specialized for round tubes. Below is a complete list of compatible alloys and sizes. Designs submitted with dimensions close to the standard sizes listed will be fabricated using those standard specifications. Follow these design for manufacturing (DFM) guidelines to ensure a smooth quoting process and efficient production:

  • Minimum bendable tube diameter: .250"
  • Maximum bendable tube diameter: 2.000"
  • Minimum bendable tube wall thickness: .035"
  • Maximum bendable tube wall thickness: .188"
  • Multiple bends can be applied to a single tube piece. For optimal results, maintain a consistent center line radius (CLR) across all bends.
  • Recommended bend radius to tube diameter ratio: 2:1 to 5:1 (using CLR), with a maximum CLR of 6”.
  • For tubes under 1 inch in diameter, the distance between bends should be at least twice the outer diameter. For tubes 1 to 2 inches, a minimum distance of 3X the outer diameter is suggested. For tubes over 2 inches, allow 4X the outer diameter between bends.
  • All cut features and end conditions should be designed for normal-to-surface cutting.

Laser Tube Cutting

EPTAHUB's laser tube cutting services cover an expanded range of round, square, and rectangular tube sizes. The following specifications outline the available dimensions by profile and alloy:

  • Minimum round outer diameter: .500"
  • Maximum round outer diameter: 6.000"
  • Minimum square or rectangular dimension: .500"
  • Maximum square or rectangular dimension: 6.000"
  • Minimum wall thickness: .035"
  • Maximum wall thickness: .500"

Round Tube Stock

EPTAHUB utilizes a diverse range of round tube stock for on-demand manufacturing. The following sections categorize metals and sizes based on their compatibility with tube bending and laser tube cutting services.

Stainless Steel Round Stock

Stainless steel 304 and 316 tubes are suitable for both bending and cutting in various configurations. 304 stainless steel is a versatile general-purpose option, while 316 offers enhanced corrosion resistance.

Round Stainless Steel 304, Welded 304

Tube Bending Sizes

TUBE OD WALL THICKNESS
.250 in. .035 in. .049 in. .065 in.
.375 in. .035 in. .049 in. .065 in.
.500 in. .035 in. .049 in. .065 in.
.625 in. .035 in. .049 in. .065 in. .120 in.
.750 in. .035 in. .049 in. .065 in. .120 in.
.875 in. .035 in. .049 in. .065 in. .120 in.
1.000 in. .035 in. .049 in. .065 in. .083 in. .120 in.
1.250 in. .035 in. .049 in. .065 in. .083 in. .120 in.
1.500 in. .035 in. .049 in. .065 in. .083 in. .120 in.
1.750 in. .065 in. .120 in.
2.000 in. .035 in. .049 in. .065 in. .083 in. .120 in.

Laser Tube Cutting Sizes

TUBE OD WALL THICKNESS
.500 in. .035 in. .049 in. .065 in.
.625 in. .035 in. .049 in. .065 in. .120 in.
.750 in. .035 in. .049 in. .065 in. .120 in.
.875 in. .035 in. .049 in. .065 in. .120 in.
1.000 in. .035 in. .049 in. .065 in. .083 in. .120 in.
1.125 in. .035 in. .065 in.
1.250 in. .035 in. .049 in. .065 in. .083 in. .120 in.
1.375 in. .049 in. .065 in.
1.500 in. .035 in. .049 in. .065 in. .083 in. .120 in.
1.750 in. .065 in. .120 in.
2.000 in. .035 in. .049 in. .065 in. .083 in. .120 in.
2.250 in. .065 in. .120 in.
2.500 in. .065 in. .083 in. .120 in.
3.000 in. .065 in. .083 in. .120 in.
3.500 in. .065 in.
4.000 in. .065 in. .083 in. .120 in.
5.000 in. .065 in.
6.000 in. .065 in. .120 in.

Round Stainless Steel 304, Seamless

Tube Bending Sizes

TUBE OD WALL THICKNESS
.250 in. .035 in. .049 in. .065 in. .083 in.
.375 in. .035 in. .049 in. .065 in. .083 in. .095 in. .120 in.
.500 in. .035 in. .049 in. .065 in. .083 in. .095 in. .120 in.
.625 in. .035 in. .049 in. .065 in. .083 in. .095 in. .120 in. .188 in.
.750 in. .035 in. .049 in. .065 in. .083 in. .095 in. .120 in.
.875 in. .035 in. .049 in. .065 in. .083 in. .095 in. .120 in. .188 in.
1.000 in. .035 in. .049 in. .065 in. .083 in. .095 in. .120 in. .188 in.
1.250 in. .035 in. .049 in. .065 in. .083 in. .120 in. .188 in.
1.500 in. .035 in. .049 in. .065 in. .083 in. .120 in. .188 in.
1.750 in. .065 in. .120 in. .188 in.
2.000 in. .065 in. .095 in. .120 in.

Tube Bending Sizes

TUBE OD WALL THICKNESS
.500 in. .035 in. .049 in. .065 in. .083 in. .095 in. .120 in. .188 in.
.625 in. .035 in. .049 in. .065 in. .083 in. .095 in. .120 in. .188 in.
.750 in. .035 in. .049 in. .065 in. .083 in. .095 in. .120 in. .188 in.
.875 in. .035 in. .049 in. .065 in. .083 in. .095 in. .120 in.
1.000 in. .035 in. .049 in. .065 in. .083 in. .095 in. .120 in. .188 in. .250 in.
1.125 in. .065 in. .120 in. .188 in.
1.250 in. .035 in. .049 in. .065 in. .083 in. .120 in. .188 in. .250 in.
1.375 in. .035 in. .049 in. .065 in. .120 in.
1.500 in. .035 in. .049 in. .065 in. .083 in. .120 in. .188 in. .250 in.
1.625 in. .065 in.
1.750 in. .065 in. .120 in. .188 in. .250 in.
2.000 in. .065 in. .095 in. .120 in. .188 in. .250 in. .375 in.
2.250 in. .065 in. .188 in. .250 in.
2.500 in. .065 in. .188 in. .250 in. .375 in.
2.750 in. .250 in. .375 in.
3.000 in. .065 in. .188 in. .250 in. .375 in.
3.250 in. .250 in.
4.000 in. .250 in.
5.000 in. .250 in.
6.000 in. .250 in. .500 in.

Round Stainless Steel 316, Welded

Tube Bending Sizes

TUBE OD WALL THICKNESS
.250 in. .035 in. .049 in. .065 in.
.375 in. .035 in. .049 in. .065 in.
.500 in. .035 in. .049 in. .065 in.
.625 in. .049 in. .065 in.
.750 in. .035 in. .049 in. .065 in.
1.000 in. .035 in. .049 in. .065 in. .120 in.
1.250 in. .065 in.
1.500 in. .065 in. .120 in.
1.750 in. .065 in.
2.000 in. .065 in. .120 in.

Laser Tube Cutting Sizes

TUBE OD WALL THICKNESS
.500 in. .035 in. .049 in. .065 in.
.625 in. .049 in. .065 in.
.750 in. .035 in. .049 in. .065 in.
1.000 in. .035 in. .049 in. .065 in. .120 in.
1.250 in. .065 in.
1.500 in. .065 in. .120 in.
1.750 in. .065 in.
2.000 in. .065 in. .120 in.
2.500 in. .065 in.
3.000 in. .065 in.
4.000 in.

Round Stainless Steel 316, Seamless

Tube Bending Sizes

TUBE OD WALL THICKNESS
.250 in. .035 in. .049 in. .065 in. .083 in.
.375 in. .035 in. .049 in. .065 in. .083 in.
.500 in. .035 in. .049 in. .065 in. .083 in. .120 in.
.625 in. .035 in. .049 in. .065 in. .083 in. .120 in.
.750 in. .035 in. .049 in. .065 in. .083 in. .120 in.
.875 in. .035 in. .049 in. .065 in. .083 in. .120 in.
1.000 in. .035 in. .049 in. .065 in. .083 in. .120 in.
1.250 in. .049 in. .065 in. .083 in. .120 in.
1.500 in. .049 in. .065 in. .120 in.
1.750 in. .065 in.
2.000 in. .065 in. .120 in.

Laser Tube Cutting Sizes

TUBE OD WALL THICKNESS
.500 in. .035 in. .049 in. .065 in. .083 in. .120 in.
.625 in. .035 in. .049 in. .065 in. .083 in. .120 in.
.750 in. .035 in. .049 in. .065 in. .083 in. .120 in.
.875 in. .035 in. .049 in. .065 in. .083 in. .120 in.
1.000 in. .035 in. .049 in. .065 in. .083 in. .120 in.
1.250 in. .049 in. .065 in. .083 in. .120 in.
1.375 in. .049 in. .065 in.
1.500 in. .049 in. .065 in. .120 in.
1.750 in. .065 in. .120 in.
2.000 in. .065 in.
2.500 in. .065 in. .120 in.
3.000 in. .065 in.

Aluminum Round Stock

Aluminum is a lightweight yet strong material suitable for numerous applications, including frames, cable routing, and structural components.

Round Aluminum 6061, Extruded

Tube Bending Sizes

TUBE OD WALL THICKNESS
.750 in. .125 in.
1.000 in. .125 in.
1.500 in. .125 in.
1.750 in. .125 in.
2.000 in. .125 in.

Laser Tube Cutting Sizes

TUBE OD WALL THICKNESS
.750 in. .125 in.
1.000 in. .125 in. .250 in.
1.125 in. .250 in.
1.250 in. .250 in.
1.500 in. .125 in. .250 in.
1.750 in. .125 in. .250 in.
2.000 in. .125 in. .250 in. .375 in.
2.250 in. .250 in.
2.500 in. .125 in. .250 in. .500 in.
2.750 in. .250 in. .500 in.
3.000 in. .125 in. .250 in. .375 in. .500 in.
3.250 in. .250 in.
3.500 in. .250 in. .375 in. .500 in.
4.000 in. .125 in. .250 in. .500 in.
4.500 in. .250 in. .500 in.
5.000 in. .125 in. .250 in. .500 in.
5.500 in. .500 in.
6.000 in. .250 in. .500 in.

Round Aluminum 6061, Draw

Tube Bending Sizes

TUBE OD WALL THICKNESS
.250 in. .035 in. .049 in. .058 in. .065 in.
.375 in. .035 in. .049 in. .058 in. .065 in.
.500 in. .035 in. .049 in. .058 in. .065 in. .083 in. .125 in.
.625 in. .035 in. .049 in. .058 in. .065 in. .125 in.
.750 in. .035 in. .049 in. .058 in. .065 in. .083 in. .125 in.
.875 in. .035 in. .049 in. .058 in. .065 in. .125 in.
1.000 in. .035 in. .049 in. .058 in. .065 in. .083 in. .095 in. .125 in. .188 in.
1.250 in. .035 in. .049 in. .058 in. .065 in. .083 in. .125 in.
1.500 in. .035 in. .049 in. .058 in. .065 in. .083 in. .095 in. .125 in.
1.750 in. .035 in. .049 in. .058 in. .065 in. .083 in.
2.000 in. .035 in. .049 in. .065 in. .083 in. .125 in.

Laser Tube Cutting Sizes

TUBE OD WALL THICKNESS
.500 in. .035 in. .049 in. .058 in. .065 in. .083 in. .125 in.
.625 in. .035 in. .049 in. .058 in. .065 in. .125 in.
.750 in. .035 in. .049 in. .058 in. .065 in. .083 in. .125 in.
.875 in. .035 in. .049 in. .058 in. .065 in. .125 in.
1.000 in. .035 in. .049 in. .058 in. .065 in. .083 in. .095 in. .125 in. .188 in. .250 in.
1.125 in. .035 in. .049 in. .058 in. .065 in. .125 in. .250 in.
1.250 in. .035 in. .049 in. .058 in. .065 in. .083 in. .125 in.
1.375 in. .035 in. .049 in. .058 in. .065 in. .083 in. .125 in.
1.500 in. .035 in. .049 in. .058 in. .065 in. .083 in. .095 in. .125 in.
1.625 in. .058 in.
1.750 in. .035 in. .049 in. .058 in. .065 in. .083 in.
2.000 in. .035 in. .049 in. .065 in. .083 in. .125 in.

Alloy Steel Round Stock

Alloy steel tubes are highly versatile, ideal for handlebars, exhaust manifolds, construction, agriculture, and automotive applications. A513-5 DOM tubing offers the widest range of sizes in this category.

Round Steel 4130, Seamless (Chromoly)

Tube Bending Sizes

TUBE OD WALL THICKNESS
.375 in. .035 in. .049 in. .058 in. .065 in. .120 in.
.500 in. .035 in. .049 in. .058 in. .065 in. .083 in. .095 in. .120 in.
.625 in. .035 in. .049 in. .058 in. .065 in. .083 in. .120 in. .188 in.
.750 in. .035 in. .049 in. .058 in. .065 in. .083 in. .095 in. .120 in. .188 in.
1.000 in. .035 in. .049 in. .058 in. .065 in. .083 in. .095 in. .120 in. .188 in.
1.250 in. .035 in. .049 in. .058 in. .065 in. .083 in. .095 in. .120 in. .188 in.
1.500 in. .035 in. .049 in. .058 in. .065 in. .083 in. .095 in. .120 in.
1.750 in. .049 in. .065 in. .083 in. .095 in. .120 in.
2.000 in. .049 in. .065 in. .083 in. .095 in. .120 in. .188 in.

Laser Tube Cutting Sizes

TUBE OD WALL THICKNESS
.500 in. .035 in. .049 in. .058 in. .065 in. .083 in. .095 in. .120 in.
.625 in. .035 in. .049 in. .058 in. .065 in. .083 in. .120 in. .188 in.
.750 in. .035 in. .049 in. .058 in. .065 in. .083 in. .095 in. .120 in. .188 in. .250 in.
1.000 in. .035 in. .049 in. .058 in. .065 in. .083 in. .095 in. .120 in. .188 in. .250 in.
1.125 in. .035 in. .049 in. .058 in. .065 in. .083 in. .095 in. .120 in. .188 in.
1.250 in. .035 in. .049 in. .058 in. .065 in. .083 in. .095 in. .120 in. .188 in.
1.500 in. .035 in. .049 in. .058 in. .065 in. .083 in. .095 in. .120 in. .250 in.
1.625 in. .035 in. .049 in. .058 in. .065 in. .083 in. .095 in. .120 in.
1.750 in. .049 in. .065 in. .083 in. .095 in. .120 in.
2.000 in. .049 in. .065 in. .083 in. .095 in. .120 in. .188 in.

Round Steel A513 Type 5, DOM (Drawn Over Mandrel)

Tube Bending Sizes

TUBE OD WALL THICKNESS
.250 in. .035 in. .065 in.
.375 in. .035 in. .049 in. .058 in. .065 in. .083 in. .095 in.
.500 in. .035 in. .049 in. .058 in. .065 in. .083 in. .095 in. .109 in. .120 in. .125 in. .134 in. .156 in. .188 in.
.625 in. .035 in. .049 in. .058 in. .065 in. .083 in. .095 in. .109 in. .120 in. .125 in. .134 in. .156 in. .188 in.
.750 in. .035 in. .049 in. .058 in. .065 in. .083 in. .095 in. .109 in. .120 in. .125 in. .134 in. .156 in. .188 in.
.875 in. .035 in. .049 in. .058 in. .065 in. .083 in. .095 in. .109 in. .120 in. .125 in. .134 in. .156 in. .188 in.
1.000 in. .035 in. .049 in. .058 in. .065 in. .083 in. .095 in. .109 in. .120 in. .125 in. .134 in. .156 in. .188 in.
1.250 in. .035 in. .049 in. .065 in. .083 in. .095 in. .109 in. .120 in. .125 in. .134 in. .156 in. .188 in.
1.500 in. .035 in. .049 in. .065 in. .083 in. .095 in. .109 in. .120 in. .125 in. .134 in. .156 in. .188 in.
1.750 in. .049 in. .065 in. .083 in. .095 in. .109 in. .120 in. .125 in. .134 in. .156 in. .188 in.
2.000 in. .049 in. .065 in. .083 in. .095 in. .109 in. .120 in. .125 in. .134 in. .156 in. .188 in.

Laser Tube Cutting Sizes

Tube OD WALL THICKNESS
.500 in. .035 in. | .049 in. | .058 in. | .065 in. | .083 in. | .095 in. | .109 in. | .120 in. | .125 in. | .134 in. | .156 in. | .188 in.
.563 in. .049 in. | .065 in. | .083 in. | .095 in. | .120 in.
.625 in. .035 in. | .049 in. | .058 in. | .065 in. | .083 in. | .095 in. | .109 in. | .120 in. | .125 in. | .134 in. | .156 in. | .188 in.
.688 in. .083 in. | .095 in. | .120 in. |
.750 in. .035 in. | .049 in. | .058 in. | .065 in. | .083 in. | .095 in. | .109 in. | .120 in. | .125 in. | .134 in. | .156 in. | .188 in. | .219 in. | .250 in.
.813 in. .065 in. | .083 in. | .095 in. | .109 in. | .120 in. | .125 in. | .156 in. | .188 in.
.875 in. .035 in. | .049 in. | .058 in. | .065 in. | .083 in. | .095 in. | .109 in. | .120 in. | .125 in. | .134 in. | .156 in. | .188 in. | .219 in. | .250 in.
.938 in. .095 in. | .134 in. | .156 in.
1.000 in. .035 in. | .049 in. | .058 in. | .065 in. | .083 in. | .095 in. | .109 in. | .120 in. | .125 in. | .134 in. | .156 in. | .188 in. | .219 in. | .250 in. | .281 in.
1.063 in. .065 in. | .083 in. | .095 in. | .109 in. | .120 in. | .125 in. | .134 in. | .156 in. | .188 in. | .250 in.
1.125 in. .049 in. | .065 in. | .083 in. | .095 in. | .109 in. | .120 in. | .125 in. | .134 in. | .156 in. | .188 in. | .219 in. | .250 in. | .281 in. | .313 in.
1.188 in. .065 in. | .083 in. | .095 in. | .120 in. | .125 in. | .156 in. | .188 in. | .219 in. | .250 in. | .313 in.
1.250 in. .035 in. | .049 in. | .065 in. | .083 in. | .095 in. | .109 in. | .120 in. | .125 in. | .134 in. | .156 in. | .188 in. | .219 in. | .250 in. | .281 in. | .313 in. | .375 in.
1.313 in. .065 in. | .083 in. | .095 in. | .109 in. | .120 in. | .134 in. | .156 in. | .188 in. | .219 in. | .250 in. | .313 in.
1.375 in. .049 in. | .065 in. | .083 in. | .095 in. | .109 in. | .120 in. | .125 in. | .134 in. | .156 in. | .188 in. | .219 in. | .250 in. | .281 in. | .313 in. | .375 in.
1.438 in. .120 in. | .188 in. | .219 in. | .250 in.
1.500 in. .035 in. | .049 in. | .065 in. | .083 in. | .095 in. | .109 in. | .120 in. | .125 in. | .134 in. | .156 in. | .188 in. | .219 in. | .250 in. | .281 in. | .313 in. | .375 in.
1.563 in. .065 in. | .095 in. | .120 in. | .125 in. | .156 in. | .188 in. | .250 in. | .375 in.
1.625 in. .058 in. | .065 in. | .083 in. | .095 in. | .109 in. | .120 in. | .134 in. | .156 in. | .188 in. | .219 in. | .250 in. | .281 in. | .313 in. | .375 in.
1.750 in. .049 in. | .065 in. | .083 in. | .095 in. | .109 in. | .120 in. | .125 in. | .134 in. | .156 in. | .188 in. | .219 in. | .250 in. | .281 in. | .313 in. | .375 in.
1.813 in. .250 in.
1.875 in. .065 in. | .095 in. | .109 in. | .120 in. | .125 in. | .156 in. | .188 in. | .219 in. | .250 in. | .281 in. | .313 in. | .375 in.
2.000 in. .049 in. | .065 in. | .083 in. | .095 in. | .109 in. | .120 in. | .125 in. | .134 in. | .156 in. | .188 in. | .219 in. | .250 in. | .281 in. | .313 in. | .375 in. | .438 in. | .500 in.
2.125 in. .065 in. | .095 in. | .120 in. | .125 in. | .156 in. | .188 in. | .219 in. | .250 in. | .281 in. | .313 in. | .375 in.
2.188 in. .250 in.
2.250 in. .065 in. | .083 in. | .095 in. | .109 in. | .120 in. | .125 in. | .134 in. | .156 in. | .188 in. | .219 in. | .250 in. | .281 in. | .313 in. | .375 in. | .438 in. | .500 in.
2.375 in. .065 in. | .095 in. | .120 in. | .125 in. | .156 in. | .188 in. | .219 in. | .250 in. | .281 in. | .313 in. | .375 in. | .438 in. | .500 in.
2.500 in. .065 in. | .083 in. | .095 in. | .109 in. | .120 in. | .125 in. | .134 in. | .156 in. | .188 in. | .219 in. | .250 in. | .281 in. | .313 in. | .375 in. | .438 in. | .500 in.
2.563 in. .250 in.
2.625 in. .065 in. | .095 in. | .109 in. | .120 in. | .156 in. | .188 in. | .219 in. | .250 in. | .313 in. | .375 in. | .500 in.
2.750 in. .065 in. | .083 in. | .095 in. | .120 in. | .125 in. | .156 in. | .188 in. | .219 in. | .250 in. | .281 in. | .313 in. | .375 in. | .438 in. | .500 in.
2.875 in. .065 in. | .120 in. | .125 in. | .156 in. | .188 in. | .219 in. | .250 in. | .281 in. | .313 in. | .375 in.
3.000 in. .065 in. | .083 in. | .095 in. | .109 in. | .120 in. | .125 in. | .134 in. | .156 in. | .188 in. | .219 in. | .250 in. | .281 in. | .313 in. | .375 in. | .438 in. | .500 in.
3.125 in. .125 in. | .188 in. | .250 in. | .313 in. | .375 in. | .438 in. | .500 in.
3.250 in. .095 in. | .120 in. | .125 in. | .134 in. | .188 in.
3.375 in. .188 in. | .250 in. | .313 in. | .375 in. | .500 in.
3.500 in. .065 in. | .083 in. | .095 in. | .120 in. | .125 in. | .134 in. | .156 in. | .188 in. | .219 in. | .250 in. | .281 in. | .375 in. | .438 in. | .500 in.
3.625 in. .188 in. | .250 in. | .313 in. | .375 in. | .438 in. | .500 in.
3.750 in. .120 in. | .125 in. | .188 in. | .250 in. | .313 in. | .375 in. | .438 in. | .500 in.
3.875 in. .188 in. | .250 in. | .375 in. | .500 in.
4.000 in. .065 in. | .083 in. | .095 in. | .120 in. | .125 in. | .134 in. | .156 in. | .188 in. | .219 in. | .250 in. | .313 in. | .375 in. | .438 in. | .500 in.
4.125 in. .188 in. | .250 in. | .313 in. | .438 in. | .500 in.
4.250 in. .095 in. | .125 in. | .188 in. | .250 in. | .313 in. | .375 in. | .438 in. | .500 in.
4.375 in. .188 in. | .250 in. | .375 in. | .500 in.
4.500 in. .095 in. | .120 in. | .125 in. | .134 in. | .156 in. | .188 in. | .219 in. | .250 in. | .313 in. | .375 in. | .438 in. | .500 in.
4.625 in. .188 in. | .250 in. | .313 in. | .375 in. | .500 in.
4.750 in. .120 in. | .125 in. | .188 in. | .250 in. | .313 in. | .375 in. | .500 in.
5.000 in. .125 in. | .188 in. | .250 in. | .313 in. | .375 in. | .438 in. | .500 in.
5.125 in. .313 in. | .500 in.
5.250 in. .120 in. | .125 in. | .188 in. | .250 in. | .313 in. | .375 in. | .500 in.
5.500 in. .120 in. | .188 in. | .250 in. | .313 in. | .375 in. | .500 in.
5.750 in. .120 in. | .188 in. | .250 in. | .375 in. | .500 in.
6.000 in. .120 in. | .125 in. | .188 in. | .250 in. | .313 in. | .375 in. | .500 in.

Round Steel A513 Type 1, HREW (Hot Rolled Electric-Welded)

Tube Bending Sizes

TUBE OD WALL THICKNESS
1.000 in. .120 in.
1.250 in. .065 in. .083 in. .120 in.
1.500 in. .083 in.
1.750 in. .065 in. .083 in. .120 in.
2.000 in. .083 in. .120 in.

Laser Tube Cutting Sizes

TUBE OD WALL THICKNESS
1.000 in. .120 in.
1.125 in. .083 in. .120 in.
1.250 in. .065 in. .083 in. .120 in.
1.375 in. .120 in.
1.500 in. .083 in.
1.625 in. .120 in.
1.750 in. .065 in. .083 in. .120 in.
1.875 in. .120 in.
2.000 in. .083 in. .120 in.
2.250 in. .120 in.
2.375 in. .120 in.
2.500 in. .065 in. .083 in. .120 in.
3.000 in. .083 in. .120 in.
3.500 in. .120 in.
4.000 in. .065 in. .083 in. .120 in.
4.500 in. .065 in. .120 in.
5.000 in. .065 in. .083 in. .120 in.
6.000 in. .120 in.

Round Steel A513 Type 1, HREW (Hot Rolled Electric-Welded)

Tube Bending Sizes

TUBE OD WALL THICKNESS
.500 in. .035 in. .049 in. .065 in.
.625 in. .035 in. .049 in.
.750 in. .035 in. .065 in.
.875 in. .049 in. .065 in.
1.000 in. .049 in. .065 in.
1.500 in. .065 in.
2.000 in. .065 in.

Laser Tube Cutting Sizes

TUBE OD WALL THICKNESS
.500 in. .035 in. .049 in. .065 in.
.625 in. .035 in. .049 in.
.750 in. .035 in. .065 in.
.875 in. .049 in. .065 in.
1.000 in. .049 in. .065 in.
1.125 in. .065 in.
1.375 in. .065 in.
1.500 in. .065 in.
2.000 in. .065 in.
2.250 in. .065 in.
3.000 in. .065 in.
3.500 in. .065 in.

Square And Rectangular Tubing

Square and rectangular tubes are ideal for creating large, cost-effective structural components. Their flat surfaces make them perfect for mechanical assemblies. These tube types are exclusively available for EPTAHUB's laser tube cutting service.

Stainless Steel Square And Rectangular Stock

Stainless steel square and rectangular tubes are used to construct strong, durable structures for industrial, processing, agricultural, and transportation applications.

Square Stainless Steel 304, Welded (Laser Tube Cutting Sizes)

WIDTH WALL THICKNESS
.500 in. .065 in.
.625 in. .065 in.
.750 in. .065 in. .120 in.
1.000 in. .049 in. .065 in. .083 in. .120 in.
1.125 in. .065 in. .083 in. .120 in.
1.500 in. .049 in. .065 in. .083 in. .120 in. .180 in.
1.750 in. .065 in. .120 in.
2.000 in. .065 in. .083 in. .120 in. .180 in. .250 in.
2.500 in. .120 in. .188 in. .250 in.
3.000 in. .120 in. .180 in. .250 in.
4.000 in. .120 in. .180 in. .188 in. .250 in.
5.000 in. .250 in.
6.000 in. .180 in. .250 in. .375 in.

Rectangle Stainless Steel 304, Welded (Laser Tube Cutting Sizes)

WIDTH HEIGHT WALL THICKNESS
1.000 in. .500 in. .065 in.
1.000 in. .750 in. .065 in.
1.500 in. .500 in. .065 in.
1.500 in. .750 in. .065 in.
1.500 in. 1.000 in. .065 in. .120 in.
2.000 in. 1.000 in. .065 in. .120 in.
2.000 in. 1.500 in. .065 in. .120 in.
3.000 in. 1.000 in. .120 in.
3.000 in. 1.500 in. .120 in. .180 in.
3.000 in. 2.000 in. .120 in. .180 in. .250 in.
4.000 in. 2.000 in. .120 in. .180 in. .250 in.
4.000 in. 3.000 in. .120 in. .180 in. .250 in.
5.000 in. 2.000 in. .180 in.
5.000 in. 3.000 in. .180 in. .250 in.
6.000 in. 2.000 in. .120 in. .180 in. .250 in.
6.000 in. 3.000 in. .180 in. .250 in.
6.000 in. 4.000 in. .180 in. .250 in.

Square Stainless Steel 316, Welded (Laser Tube Cutting Sizes)

WIDTH WALL THICKNESS
1.000 in. .065 in. .120 in.
1.250 in. .065 in. .120 in.
1.500 in. .065 in. .120 in.
2.000 in. .065 in. .120 in. .188 in. .250 in.
3.000 in. .120 in. .180 in. .250 in.
4.000 in. .120 in. .188 in. .250 in.

Rectangle Stainless Steel 316, Welded (Laser Tube Cutting Sizes)

WIDTH HEIGHT WALL THICKNESS
2.000 in. 1.000 in. .120 in.
3.000 in. 1.000 in. .065 in. .120 in.
3.000 in. 2.000 in. .120 in.
4.000 in. 2.000 in. .120 in. .250 in.

Aluminum Square And Rectangular Stock

Aluminum 6061 square and rectangular tubes are commonly used in EPTAHUB's laser tube cutting services to create lightweight structural components for framing, overhead fixtures, brackets, and shelving.

Square Aluminum 6061, Extruded (Laser Tube Cutting Sizes)

WIDTH WALL THICKNESS
1.000 in. .125 in.
1.125 in. .125 in.
1.500 in. .125 in. .188 in. .250 in.
1.750 in. .125 in.
2.000 in. .125 in. .188 in. .250 in.
2.500 in. .125 in. .250 in.
3.000 in. .125 in. .188 in. .250 in.
4.000 in. .188 in. .250 in. .375 in. .500 in.
5.000 in. .188 in. .250 in.
6.000 in. .188 in. .250 in. .375 in. .500 in.

Rectangle Aluminum 6061, Extruded (Laser Tube Cutting Sizes)

WIDTH HEIGHT WALL THICKNESS
1.500 in. 1.000 in. .125 in.
2.000 in. 1.000 in. .125 in.
2.000 in. 1.500 in. .125 in.
3.000 in. 1.000 in. .125 in.
3.000 in. 2.000 in. .125 in. .250 in.
4.000 in. 2.000 in. .125 in. .188 in. .250 in.
4.000 in. 3.000 in. .125 in. .250 in.
6.000 in. 2.000 in. .125 in. .250 in.
6.000 in. 4.000 in. .125 in. .250 in. .500 in.

Alloy Steel Square And Rectangular Stock

A513 and 4130 chromoly alloy steel square/rectangular tubes provide high strength and durability for structural applications. 4130 offers an excellent strength-to-weight ratio, whereas A513 is commonly used in shelving and automotive frames.

Square Steel A513 (Laser Tube Cutting Sizes)

WIDTH WALL THICKNESS
.500 in. .049 in. .065 in.
.625 in. .049 in. .065 in.
.750 in. .049 in. .065 in. .083 in. .095 in. .120 in.
.875 in. .049 in. .065 in.
1.000 in. .049 in. .065 in. .072 in. .083 in. .109 in. .120 in.
1.125 in. .049 in. .065 in.
1.250 in. .049 in. .065 in. .083 in. .095 in. .109 in. .120 in.
1.500 in. .049 in. .065 in. .083 in. .095 in. .109 in. .120 in.
1.750 in. .065 in. .083 in. .095 in. .109 in. .120 in.
2.000 in. .049 in. .065 in. .083 in. .095 in. .109 in. .120 in.
2.500 in. .065 in. .083 in. .095 in. .109 in. .120 in.
3.000 in. .083 in.

Rectangle Steel A513 (Laser Tube Cutting Sizes)

WIDTH HEIGHT WALL THICKNESS
1.000 in. .500 in. .049 in. .065 in.
1.000 in. .750 in. .065 in.
1.500 in. .500 in. .065 in.
1.500 in. .750 in. .065 in. .083 in. .120 in.
1.500 in. 1.000 in. .049 in. .065 in. .083 in. .120 in.
2.000 in. .750 in. .065 in.
2.000 in. 1.000 in. .049 in. .065 in. .083 in. .095 in. .109 in. .120 in.
2.000 in. 1.250 in. .065 in. .083 in. .120 in.
2.000 in. 1.500 in. .065 in. .083 in. .120 in.
2.500 in. 1.000 in. .065 in. .083 in. .120 in.
2.500 in. 1.250 in. .083 in.
2.500 in. 1.500 in. .065 in. .083 in. .120 in.
3.000 in. 1.000 in. .065 in. .083 in. .120 in.
3.000 in. 1.500 in. .065 in. .083 in. .095 in. .109 in. .120 in.
3.000 in. 2.000 in. .065 in. .083 in. .095 in. .120 in.
4.000 in. 1.500 in. .120 in.
4.000 in. 2.000 in. .083 in. .120 in.

Square Steel 4130, Cold Drawn Seamless (Chromoly) (Laser Tube Cutting Sizes)

WIDTH WALL THICKNESS
.500 in. .035 in.
.625 in. .049 in. .065 in.
.750 in. .035 in. .065 in.
1.000 in. .035 in. .049 in. .065 in.

Rectangle Steel 4130, Cold Drawn Seamless (Chromoly)(Laser Tube Cutting Sizes)

WIDTH HEIGHT WALL THICKNESS
1.500 in. 1.000 in. .065 in.
1.750 in. 1.000 in. .065 in.
2.000 in. 1.000 in. .065 in.

Tube Fabrication Services

High-quality laser tube cutting for square, rectangular, and round metal profiles

Laser Tube Cutting Offerings

EPTAHUB provides precision laser tube cutting services for metal tubes, including rectangular, square, and round profiles. International prototype pricing includes all applicable tariffs.

Learn more about Laser Tube Cutting Services

Precision tube bending services for round metal tube stock and industrial frames

Tube Bending Solutions

EPTAHUB provides precision tube bending capabilities tailored for round metal tube stock, designed to align with your specific project requirements.

Learn more about Tube Bending Services

×

EPTAHUB Professional & Intelligent Quoting

Our automated quoting system gives you instant pricing so you can quickly estimate your project costs.

For high-precision or complex parts, our senior account managers can provide more detailed quotes and help you find the best overall solution for your needs.

Get Instant Quote Get a Quote Instantly — ⭐⭐⭐
Request Expert Quote Precise Quotes — ⭐⭐⭐⭐⭐
